| 性能Performance |
|
| 系統System |
平衡調溫控制系統Balanced temperature control system |
| 循環方式Circulation method |
強制空氣循環 Forced air circulation |
| 溫度范圍Temperature range |
-45（or -40）～+ |
| 溫度波動度Temp.fluctuation |
≤ |
| 溫度梯度Temp. gradient |
≤ |
| 溫度偏差Temp. variation |
± |
| 升溫時間Increasing temp. time |
-20→+ |
| 約30～40分鐘 Approx. 30～60min（升溫時速：1.0～3.0℃/min） |
|
| 降溫時間Reducing temp. time |
+20→ |
| 構成Components |
|
| 內箱材料Interior material |
不銹鋼SUS304 Stainless steel SUS304 |
| 外殼材料Exterior material |
冷軋鋼板表面環氧粉末靜電噴涂 Electrostatic spraying of epoxy powder on cold-rolled steel sheet |
| 隔熱材料Heat insulating material |
高密度聚氨脂發泡+玻璃棉Rigid polyurethane foam+glass wool |
| 加熱器Heater |
鎳鉻合金電熱絲式加熱器Ni-chrome strip wire heater |
| 攪拌風扇Circulating fan |
多翼式離心風扇Multi-wing centrifugal blow fan |
| 馬達Motor |
冷凝器型Condenser type, 90W 1PCS |
| 溫度傳感器Sensor |
鉑電阻PT100Ω |
| 觀察窗Viewing window |
發熱體內嵌式玻璃Glass incorporating heat generator |
| 電纜孔Cable hole |
內徑Φ50 Inside diameter Φ50 |
| 腳輪Caster wheel |
可固定的腳輪Locking Caster wheel |
| 控制器Controller |
|
| 溫度控制器Temp. controller |
微電腦PID控制PID control by microprocessor |
| 溫度設定方式Temp. setting method |
按上下鍵數字設定Digital setting with the UP/DOWN key 設定溫度Set temp./指示溫度Instructions temp.：±0.1℃ |
| 溫度顯示方式Temp. display method |
LED數字顯示Digital display by LED |
| 程序Programs |
4組程序10段/組4 programs 10 steps/ program |
| 操作功能Operation function |
恒定溫度操作,程序溫度操作 Fixed temperature operation, Progrmmable operation |
| 冷凍系統Refrigeration system |
|
| 制冷方式Refrigerating mode |
機械式單級壓縮制冷Mechanical single-stage refrigerator system |
| 風冷冷凝器Air-cooled condenser |
|
| 制冷機Refrigerator |
全密閉型旋轉壓縮機Hermetically sealed rotary compressor |
| 制冷劑Refrigerant |
環保冷媒Non-chlorofluorocarbon Coolant R404A |
| 冷凝器Condenser |
翅片式換熱器Finned heat exchanger |
| 蒸發器Evaporator |
翅片管蒸發器Finned tube Evaporator |
| 安全裝置Safe Device |
|
| 獨立超溫保護,過電流斷路器，壓縮機過載保護開關、超壓、過熱保護Independence overtemp. protection/over current breaker/ Refrigerator overload relay,refrigerator overpressure and overheat protection |
|
| 規格Standard |
|
| 內箱尺寸Internal dimensions |
400×500×500mm (D×W×H) |
| 外部尺寸Exterior dimensions |
約850×1000× |
| 內容積Internal capacity |
100L |
| 電源Power source |
380V/50Hz，約4.5KW(-40℃～+ |
| 可選附件Optional Accesseies |
|
| 增加擱板, |
|
